Sliding systems, which stand out with their easy use among glass balcony systems today, provide a panoramic view with minimum profile and maximum glass feature and offer wider and more comfortable living spaces. It is especially preferred in areas such as balconies, terraces and winter gardens outside the living area. How the system works: It opens and closes by sliding the panels to the right or left parallel to each other. System options: A system with a threshold is preferred for sections without a transition area, and a system without a threshold is preferred for sections with a transition area.
Considering the shortcomings of the sliding systems used as Lockwin, we have produced alternative series depending on the purpose of use. It consists of ANKA THERMO sliding, ANKA DOUBLE GLASS sliding and L.EGE sliding series suitable for 8-10 mm glass use, the profiles of which are designed with polyamide barrier for water that captured between inner surface of profiles due to adverse external weather conditions.
Motorized system option;The system is opened and closed with the movement of the panel connected to the belt mechanism in the upper part of the system and the motor on the side. the motor receives the movement command from the control or button.
Aluminum Profiles: EN6063 TS-F22 heat insulated
Profile color options:Rall painted, wood veneer
Glass options:22mm Combination insulating glass
System maximum height:2800mm
Panel combination:2,3,4,5- 2+2,3+3,4+4,5+5
Panel Maximum weight:80kg
5x Threshold bottom Case(Width:184mm-Height:45mm)
4x Threshold bottom Case(Width:147mm-Height:45mm)
3x Threshold bottom Case(Width:110mm-Height:45mm)
5x Without Threshold Bottom Case(Width:184mm-Height:18mm)
4x Without Threshold Bottom Case(Width:147mm-Height:18mm)
3x Without Threshold Bottom Case(Width:110mm-Height:18mm)
Flat Finish Profile
Single-sided Finished Profile
Finishing profile with double side handles
Center joint Profile
Locked Lock Option
Window Handle Option
Section view
Motorised System Option
